$3,899.00
The stock transmission is designed to handle the output of the stock engine, but not much more. Increase the durability of your drivetrain with a BD transmission. All transmissions come...
Availability: Out Of Stock
Sku: 1064422F
Vendor: BD Diesel

The stock transmission is designed to handle the output of the stock engine, but not much more. Increase the durability of your drivetrain with a BD transmission. All transmissions come with BD's heavy duty transmission pan and most packages come bundled with our auxiliary transmission filter kit for added protection!

FEATURES
  • Machined center support
  • Machined intermediate piston
  • Machined low/reverse pressure plate
  • Machined rear ring gear hub
  • Added lube circuits to OD planet
  • Added lube and support to output and intermediate shafts
  • Replaced all aluminum planetaries with steel
  • Drilled and tapped direct and intermediate feeds to prevent leaks at case
  • Re-programmed accumulator body
  • Full shift kit with line mod valve to increase pressures
  • Accumulator body enhanced oil flow
  • Increased cooler pressure
  • Increased pressure to converter
  • Creates positive clutch application
  • Created lube circuit for towing in overdrive
  • 1990-2003 include auxiliary frame mounted full flow filter kit
  • Clutch Count: COAST CLUTCH 2
  • Clutch Count: FORWARD 5
  • Clutch Count: DIRECT 5
  • Clutch Count: LOW REVERSE 7
  • Clutch Count: INTERMEDIATE 4
  • Clutch Count: OVERDRIVE 4
  • Pan adds 6qt extra oil capacity
  • Fully rollerized geartrain
  • Tighter clutch packs that provide a quicker shift
  • 30%-40% more clutch material with additional steels
  • Improved internal lubrication by adding high power boost valves
  • Reworked front pump
  • Improved bearing designs
  • Upgrade supports
  • Upgraded sprags
  • Sure-loc snap rings
  • Solenoids hard wiring providing high temperature resistance
  • Increase the durability of your drivetrain
  • Revised oil circuits
  • Handles up to 300% more power and torque than the stock transmission
  • Extra clutches and stronger internals
  • BD rigid aluminum heavy duty transmission pan
  • Pan reduces case flex
  • Pan reduces internal oil leakage
  • Pan heat-dissipating fins keep temperature down
  • Pan magnetic drain plug
  • Not warranted for Race or Sled Pull use
  • Each transmission is dyno tested
INSTALL TIME
  • 5 Hours
WARRANTY
Parts
  • 36-Months
  • 150,000 Miles
Labour
  • 12-Months
  • 24,000 miles
Note
  • No Race abuse covered. Remote filter required for inspection with cooler flow rate in GPM at Oil/Air transmission cooler outlet.
NOTE
  • Add "PTO" to part number for PTO provision (i.e. 1064444FPTO or 1064444FPTOLR)
  • BD torque converter must be installed at the time of installation of the transmission - use of a 3rd party or OE converter will invalidate the transmission warranty
EMISSIONS
  • This product does not require an EO in California. By nature of its design, it is legal for sale and use in all 50 states. Replacement parts included. (EMS:4)
